DAB Evosta3 80/180X (1"1/4) Circulating Pump

SKU
60186085
Special Price £282.95 £235.79 Regular Price £471.58 £392.98

Check Delivery is available in your area:



Free Standard Delivery On Most Products Over £100 ex VAT
SERVICE & MAINTENANCE
5 Year Warranty

Need help with your order?

Phone icon

Call us today 0333 323 2329

DAB Evosta3 80/180X Circulating Pump

The new DAB EVOSTA 3 electronic circulators replacing the previous Evotron and Evosta.

DAB first smart circulator, offers unique features thanks to the new DAB 4.0 in terms of assisting the installer and improving the performance of the domestic cooling or heating systems. Combining the strength of an mechanical circulator with the benefits of the electronic circulator.

IPX5 certified degree of protection prevents infiltration of water in the mechanics and electronics meand faults are reduced to a minimum.

Designed with front electronics, the new user interface with illuminated display and sequential button with immediate feedback makes easier the setting and readability under all conditions. The EVOSTA 3 version has a display showing the instantaneous flow rate, the instantaneous head and the instantaneous power consumption in Watts. The pumps have nine settings that can be selected scrolling the MODE button. Three LED lights on the facia show the current setting.

Eadsy access to the airvent plug providing access to the shaft for unblocking in case of seizure and automatic degassing.

The range of EVOSTA 3 circulators is the perfect replacement for old three-speed circulators due to its compact size and all-round performance. The circulator can now be replaced easily: the new interchangeable power connector of the Evosta 3 range can be used with connection plugs of other competitors without the need to rewire all the electrical connections. Even the most awkward replacement is now quick and easy.

Construction Features

Cast iron pump body with cataphoresis paint coating and wet rotor motor. Steel motor casing, technopolymer impeller. Ceramic motor shaft on ceramic bushings lubricated by the pumped liquid. Stainless steel rotor liner, stator liner and closing flange. Graphite thrust ring. EPDM seal ring and brass bleeding plug. Thanks to the internal protection of the motor, the pump does not require any overload protection.

Suitable for pumped liquids clean, free of solids and mineral oils, non-viscous, chemically neutral, with properties similar to water (glycol max 30%)

Technical Data

Manufacturer DAB
Model Evosta 80/180X (1"1/4)
Part Number 60186085
Warranty 5 Years
Max Flow 70 l/m
Max Head 8m
Voltage 230V 1Ph 50Hz
Centre distance 180mm
Full Load Current (FLC) 0.053-0.47A
Motor Size (kW/W) 55W
Dimensions 144.1mm B x 180mm L x 91mm H
Pump Body Material Cast Iron
Pump connection DN30 THREADED (G - 2")
Liquid temperature range from -10 °C to +110°C
Working pressure 10 bar (1000 kPa)
Protection rating IPX5
Insulation class F
More Information
Product Type Heating Circulation Pump
Custom Shipping 0.000000
Manufacturer DAB Pumps
Warranty 5 Year Warranty
Power Supply 220V-240V Single Phase
Product Code 60186085
System Type Heating
