Grundfos UPS 40-80FN (250) Hot Water Service Circulator

SKU
95906774
Special Price £1,661.58 £1,384.65 Regular Price £1,954.80 £1,629.00

Check Delivery is available in your area:



Free Standard Delivery On Most Products Over £100 ex VAT
SERVICE & MAINTENANCE
2 Year Warranty

Need help with your order?

Phone icon

Call us today 0333 323 2329

Grundfos UPS 40-80FN (250) Hot Water Service Circulator - No flanges

The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricatd by the pumped liquid. The pump has 3-step speed selector. The pump is characterized by:

  • Ceramic shaft and radial bearings.
  • Carbon axial bearing.
  • Stainless steel rotor can and bearing plate.
  • Corrosion-resistant impeller, Composite, PES/PP.
  • Stainless steel pump housing.

The motor is a 1-phase motor. No additional motor protection is required.

Technical Materials Installation Liquid
TF class: 110 Pump housing: Stainless steel Amb. max at 80 dgr C liquid: 40°C Pumped liquid: Water
  Pump housing: DIN W.-Nr.1.4301 Maximum operating pressure: 10 bar Liquid temperature range: -25 .. 110°C
  Impeller: Composite, PES/PP Flange standard: DIN Liquid temperature during operation: 60°C
    Pipe connection: DN 40 Density: 983.2kg/m³
    Pressure rating: PN 6 / PN 10
    Port-to-port length: 250mm
Electrical data
C run: 4 µF
Power input in speed 1: 135 W
Power input in speed 2: 200 W
Max. power input: 220 W
Mains frequency: 50 Hz
Rated voltage: 1 x 230 V
Current in speed 1: 0.6 A
Current in speed 2: 0.9 A
Current in speed 3: 0.98 A
Capacitor size - run: 4 µF
Enclosure class (IEC 34-5): X2D
Insulation class (IEC 85): F

Union sets, valves and flange sets for pumps supplied with no fittings/flanges are listed separately and need to be ordered as an extra item.

More Information
Product Type Hot Water Circulation Pump
Custom Shipping 0.000000
Manufacturer Grundfos
Warranty 2 Year Warranty
Product Code 95906774
