Stuart Turner MainsBoost 200SH-1-22 System

SKU
44747
Special Price £928.20 £773.50 Regular Price £1,428.00 £1,190.00

Check Delivery is available in your area:



Free Standard Delivery On Most Products Over £100 ex VAT
SERVICE & MAINTENANCE
5 Year Warranty

Need help with your order?

Phone icon

Call us today 0333 323 2329

Stuart Turner MainsBoost 200SH-1-22 Water Performance System



The Mainsboost MB 200SH features a nominal vessel size of 200 litres and a pressurised water holding capacity of approximately 110 litres. Designed to be installed horizontally in installation situations where vertical space may be restricted, the Mainsboost MB 200SH is supplied with a compatible mounting cradle. Available in single, twin and triple vessel options, each unit is supplied with a comprehensive Upstream Line-In Kit (ULK) featuring 22 mm pipe diameter fittings. Constructed from an epoxy coated steel body and a highly durable virgin butyl diaphragm, all Mainsboost vessels are WRAS Approved and come with a 5 year guarantee.



Model Vessel Capacity (Litres) Vessel Quantity ULK Kit (mm)
MBP 200SH-1-22 110 1 22



Mainsboost Charger MJ3 Pumps

This pump is used in conjunction with Mainsboost Steel Pressure Vessels, providing a direct on mains pump solution to offer increased water pressure and flow when the incoming mains cold water pressure does not meet minimum requirements. Mainsboost Charger MJ3 pump units are mounted directly onto the Mainsboost vessel and options are available suitable for use with vertical or horizontally oriented vessels. The Mainsboost Charger MJ3 will boost water pressure up to 3.5 bar and an optional sound attenuation cover is available if the system is to be installed in a location where noise levels are to be kept to a minimum. All Mainsboost Charger MJ3 pumps feature an unique 'energy saving bypass' which means that the pump only runs when it needs to, they are also WRAS Approved and come with an industry leading 5 year guarantee as standard.



Mainsboost Charger MBC 12 Pumps

This pump is used in conjunction with Mainsboost Steel and Composite Pressure Vessels, providing a direct on mains pump solution to offer increased water pressure and flow when the incoming mains cold water pressure does not meet minimum requirements. Mainsboost Charger MBC 12 pump units are wall mounted, allowing the pump to be located remotely from the Mainsboost vessel without restricting performance. Housed within a robust steel enclosure lined with effective noise reduction foam, the Mainsboost Charger MBC 12 will boost water pressure up to 3.5 bar. All Mainsboost Charger pumps are WRAS Approved and come with an industry leading 5 year guarantee as standard. MBC 12 pumps are available with 22 mm or 28 mm bypass connection kits as standard, with larger kits of up to 65 mm for bespoke commercial systems available on request.

More Information
Product Type Pressure Vessels
Custom Shipping 0.000000
Manufacturer Stuart Turner
Model Range MainsBoost Range
Warranty 5 Year Warranty
Dimensions 540 x 1026 x 558mm high (vessel only)
Product Code 44747
Material Epoxy Coated Steel Body
Orientation Horizontal
